H-1300
Feature
1.Touch screen control.
2.Hydraulic band tension control.
3.Idle wheel motion detector for blade jam/break shut-off.
4.Carbide guides with hydraulic control.
5.Power-driven saw-band brush.
6.Hydraulic shuttle vise for stock feeding.
1.Touch screen control.
2.Hydraulic band tension control.
3.Idle wheel motion detector for blade jam/break shut-off.
4.Carbide guides with hydraulic control.
5.Power-driven saw-band brush.
6.Hydraulic shuttle vise for stock feeding.
| SPEC./MODEL | H-1300 | |||||
| Cutting Capacity | mm | 1300 or 1300Wx 1300H | ||||
| in | 51 or 51Wx 51H | |||||
| Blade Size | MM | 80W x 1.6t x 12300L | ||||
| IN | 3.15W x 0.063t x 484.25L | |||||
| Blade Speed | M/min | Variable Speed 12-60 | ||||
| F/min | Variable Speed 39-197 | |||||
| Motor Output | HP | Blade 20, Hyd. 5, Coolant 1/4 | ||||
| KW | Blade 15, Hyd. 3.73, Coolant 0.19 | |||||
| Shipping Volume (L x W x H) |
mm | 5830 x 2150 x 3770 | ||||
| Ft | 19.13 x 7.05 x 12.37 | |||||
| N.W./G.W. | kg | 16000/17500 | ||||
| Ib | 35200/38500 | |||||
