Metal CNC Moving Column Machine Center HB-4D Heavy Series

HB

Feature

1. Automatic multiple machining center with functions of milling, drilling, tapping, routing, chamfering, applicable for various length of profile, Steel, Copper, Aluminum.

2. Automatic chip conveyer BT40 spindle guarantee high rigidity.

3. Protection door provide safety and cleanness.

4.Arm-type tool magazine take 2 second only for tool changing in advance.

5.Casting machine, suitable for high precision machining, strong stability.

6.It has the function of B-axis rotation, which can be rotated to process angles, and has high processing accuracy. It is suitable for the automotive industry (auto bumper, sunroof track, car luggage rack, etc.) and the processing of special-shaped curved surface materials

Specifications

TRAVEL

Model HB
X-Axis Stroke 2500-8500mm
Y-Axis Stroke 660 mm
Z-Axis Stroke 750 mm

SPINDLE

Spindle Speed 20000r.p.m
Spindle Taper BBT40

TOOLS

Tool Changer Format Disc type
Pull Studs Format 45°
Tool Capacity 24 pcs
Tool Change Time 2 ses

MOVING SPEED

X-Axis Moving Speed 60 m/min
Y / Z-Axis Moving Speed 28/28 m/min
Feeding Speed 20000 mm/min

POWER OF MOTOR

Spindle Driven Motor 20.0kw
X / Y / Z Driven Motor 4.0/4.0/4.0 kw

LUBRICATING SYSTEM

Lubricating System Automative lubricating
Cooling System  Water cooling system
 Spraying cooling system

PRECISION

Position Precisionof X Axis 0.03 mm
Position Precision of Y / Z Axis 0.02mm
Repeating Precision (X / Y / Z) 0.02mm

SIZE OF MACHINE

Air Pressure 6 kg/cm
Operation System FANUC/SIEMENS
Height 3300 mm
Area 6500-13000*3400 mm
Weight 11000-19000kg
