High-Precision Linear Y-Axis

The true linear Y-axis structure provides exceptional straightness and positioning accuracy. Compared with virtual Y-axis systems that require simultaneous multi-axis interpolation, it delivers superior milling precision and stability. Combined with a high‑rigidity slide design, it enhances cutting stability and ensures excellent geometric accuracy during complex multi-process machining.

High-Rigidity 75° Slant-Bed

The 75° slant-bed design delivers excellent chip evacuation and operator accessibility, while lowering the machine’s center of gravity to further enhance structural rigidity. This design effectively suppresses machining vibration and ensures stability under high-dynamic cutting conditions, providing an ideal foundation for process integration and high-efficiency production.

High-Efficiency Turn-Mill Machining

The standard 12‑station live tooling power turret, combined with Y‑axis capability, enables high‑efficiency turn‑mill machining and multi-process integration in a single setup. Tool capacity can be optionally expanded to 16 stations, providing greater flexibility for complex part machining while significantly reducing downtime caused by repeated workpiece setups.

CS-Axis Positioning and Braking System

The main and sub-spindle CS-axis positioning system utilizes a precision optical rotary encoder, providing multi-point positioning capability with a minimum incremental angle of 0.001°. Combined with a high-performance braking system, it securely locks the machining position, enabling precise multi-angle milling and a wide range of complex machining applications with excellent stability.

Machining with Main and Sub Spindles

Equipped with a sub-spindle, the machine supports automatic part transfer and reverse-side machining, enabling complete machining of both ends of the workpiece in a single setup. This technology significantly reduces manual handling and cumulative errors caused by secondary clamping, while greatly improving machining efficiency—making it an ideal solution for high-precision, highly reliable automated production lines.
